The patent focuses on sensors like the TouchID, pressure sensors, health sensors, optical sensors such as self-mixing sensors and light detection and ranging (LiDAR) sensors, gaze tracking sensors, and more. The patent also mentions the use of various input-output devices such as buttons, touch sensors, touch pads, microphones, and accelerometers to gather user input.
FIG 3 below shows a cross-sectional side view of a display stack that partially covers a sensor. FIG 5, on the other hand, shows a top view of an illustration that demonstrates how the sensors could be positioned under the display.
This patent extends upon technology that was previously reported on, back in April 2022, that aimed to eliminate the notch on the iPhone and reposition the TrueDepth camera system behind the display. With this patent, Apple has taken another step forward on its journey to a fully bezel-less iPhone.
